Transmitter port frequencyrange：13.75 to 14.50GHz
Transmitter port VSWRmaximum：1.25:1
LNB port frequency range：10.70 to 12.75GHz
LNB port VSWR maximumTransmitter/LNBcross polarizationminimum：40dB
Transmitter port toLNB port isolation atTx frequencyminimum：85 dB
Transmitter port tofeed port insertionloss maximum：0.2 dB
Feed port to LNB portinsertionloss maximum：0.4 dB
Feedhorn port waveguide：WC75 withthreaded holes
Transmitter port waveguide:WR75 withthrough holes
LNB port waveguide:WR75 withthrough holes
Dimensions
Weight:108(L)x 149(W)x 117 (H)mm
(4.25x1.93x4.59 in)390 g/13.8 ozmax
